Four-column hydraulic lift 5.5t LAUNCH TLT-455W adapted for wheel alignment

Four-post hydraulic lift Launch 5.5t for wheel alignment

Country of origin: China, warranty period – 24 months

Four-post hydraulic lift designed for lifting cars of various sizes and wheel alignment tasks in service stations and workshops. Equipped with an axle lift, side-shift plates, and turntables for wheel alignment. A reliable safety system ensures safe operation throughout the lift.

Features:

• Hydraulic lift with a lifting capacity of 5.5 tons
• Axle lift with a lifting capacity of 2 tons
• Side-shift plates and turntables for wheel alignment
• Adjustable track distance in three positions (1445 - 1595 mm)
• Overload, tension, and cable break protection
• Safety lock throughout the lifting range
• Protection against pipe breakage and hose failures
• Safety valve for secure lowering and foot pinch protection
• Electromechanical upper switch to prevent collision with the top
• 4 steel cables for force equalization
• Loose cable protection

Technical specifications:

• Lifting capacity: 5500 kg
• Height: 2172 mm
• Width: 3445 mm
• Lifting height: 1900 mm
• Lowest height: 245 mm
• Track length: 5600 mm
• Lifting time: 70 s
• Motor power: 2.2 kW
• Voltage: 380 V / 50 Hz
• Oil volume: 12 l
• Weight: 1550 kg
