Touchless wheel alignment check system Innovare FastLign

Innovare FastLign Contactless Wheel Alignment Inspection System for Vehicles

Features:

• Quick inspection – determines vehicle chassis condition in just 3 seconds
• Fully automatic system – no additional operator actions required
• Contactless vehicle scanning – performed even while the vehicle is moving
• High-precision lasers – same type used in the aviation industry
• Two-way traffic flow support – optimizes workflow
• Integrated cameras – capture vehicle wheel and body defects
• Multiple LED indicators – clear system status information
• Additional body defect inspection – using BL Innovare BodyGuard technology

Wheel Alignment Inspection:

• Multilayered lighting – activates when a vehicle approaches
• Integrated license plate recognition cameras – links data to specific vehicles
• High-precision lasers – ensure impeccable measurement accuracy

LED indicator system:

• Green – all data successfully scanned
• Red – system is not operational
• Blue – vehicle approaching
• Yellow – vehicle scanning in progress
• White – system is connected to the network

Vehicle Body Defect Inspection System:

• Integrated Smart lighting – highlights vehicle imperfections
• Automatic recording cameras – capture wheel and body defects
• Option to integrate a tire tread depth scanner – provides additional vehicle data

Technical Specifications:

• Column distance: 2700 – 3000 mm
• Operating temperature: -10°C to +50°C
• Power supply: 240 V / 50 Hz
• Energy consumption: 300 W
• Permissible vehicle speed: 3 – 5 km/h
• Internet connection requirement: 15 Mbps wired connection
• Internet cable requirements: 16 AWG 2 – copper, 1 – Cat6
• Maximum cable length from column to post: 25 m

Dimensions with cameras:

• FastLign EVO: 464 x 180 x 1078 mm
• FastLign Plus: 464 x 180 x 2047 mm
• Base dimensions: 610 x 180 mm
• Server box dimensions: 413 x 504 x 128 mm

Installation Recommendations:

• The system must be installed on a level surface
• Vehicles must drive in a straight trajectory
• Avoid direct sunlight exposure on the system

Models Options:

• FastLign EVO:
• FastLign Plus:
• Annual wheel alignment inspection license:
• EVO license (<100 vehicles per day):
• EVO additional license (+100 vehicles):
• Plus license (<100 vehicles per day):
• Plus additional license (+100 vehicles):

Optional Accessories:

• Tire tread depth scanner – enables monitoring of even more vehicle data
