Electro-hydraulic press 75 ton
Electro-hydraulic press 75 ton
New

Electro-hydraulic press 75 ton

  • SKU: BD70471
2,700.00 €

Prices shown include tax

Send Message

Description

Electro-hydraulic Press 75 Ton

Country of origin: China, warranty period - 24 months

This 75-ton electrohydraulic press is designed for use in industrial production processes and spare part assembly lines. It efficiently performs metal component pressing, riveting, and forming tasks, making it ideal for intensive use in mechanical workshops, metal processing, or assembly plants. Its robust construction, simple operation, and wide working range allow it to adapt to various production needs.

Features:
  • Powerful 75-ton pressing force
  • 1.5 kW motor power ensures efficient operation
  • Wide working range – from 170 to 1000 mm
  • Reliable construction and easy maintenance
  • Spacious working table – 800 mm wide
  • Compact outer dimensions for easy integration into the work environment
  • Suitable for use at altitudes up to 1000 meters above sea level
  • Resistant to dust, non-aggressive, and non-flammable environments
Technical specifications:
  • Pressing force: 75 tons
  • Stroke: 250 mm
  • Voltage: 380 V
  • Motor power: 1.5 kW
  • Working range: 170–1000 mm
  • Bed width (inner): 800 mm
  • Product dimensions: 1140 × 2010 × 740 mm
  • Net weight: 410 kg
  • Gross weight: 460 kg
  • Packing dimensions: 1110 × 430 × 2160 mm
  • Operating temperature: -5 ℃ to +40 ℃
  • Storage temperature: -25 ℃ to +55 ℃
  • Shipping temperature: -25 ℃ to +70 ℃ (not exceeding 24 hours)
  • Humidity: up to 85% relative humidity at 40 ℃ (non-condensing)
  • Ambient light: >300 LUX
  • Operating altitude: up to 1000 meters
  • Atmosphere: non-flammable, non-corrosive, dust-free
