Automatic wheel balancing machine BD-610

Automatic wheel balancing machine BD-610

Features:

• The main wheel balancing shaft is 40 mm in diameter. Longitudinal surface grinding and an excellent heat treatment process were applied to its processing. The aluminum drive pulley is corrosion resistant. For these reasons, the main shaft can be used safely and reliably for many years.
• Side Hardware Pins - Allows easy access to balance cones and other accessories.
• Control panel - it is equipped with an LED screen with special buttons, with the help of which you can enter the necessary data or select a balancing program. Also, other LEDs will show you the parameters and results of the wheel imbalance and the location of the balance.
• The 2D ruler is made of aluminum alloy and has extremely accurate measurement parameters, so with its help you can get very accurate measurement results and automatically enter wheel data into the balancing machine. Also, using this ruler, you will be able to more easily mark the place where the balancing weight should be glued.
• Wheel guard is a standard guard that can be used to control the start and stop operations of the balancing machine.
• Balancing Operations – The balancer has full wheel balancing operations such as dynamic balancing, static balancing, 3 ALU rim balancing modes and freely adjustable OPT function.

Technical parameters:

• Diameter of balanced rims: 10" - 28"
• Maximum wheel diameter: 1000 mm
• Wheel width: 1.5" - 20" | 38 - 510 mm
• Rotation speed, during balancing: 200 rpm
• Maximum wheel weight: 70 kg
• Balancing accuracy: ± 1 g
• Motor power: 0.25 kW

Standard equipment:

• Balancing cones of different dimensions x 4 pcs.
• Wheel width measuring ruler x 1 pc.
• Quick fix nut x 1 pc.
• 100 g calibration weight x 1 pc.
• Pliers, for working with weights x 1 pc.
• Cone spring x 1 pc.
• Mounting adapter with birth protection x 1 pc.
