Tire changer BD-810

Semi-automatic tire changer BD-810

Features:

• Steel tire mounting head - This head ensures durability and has replaceable plastic guards to protect rims from scratches.
• Rim Clamps are self-centering, that use two pneumatic cylinders to ensure a safe and secure locking of rims.
• Removable pedal mechanism - simpler and faster servicing.
• Retractable Mounting Arm - The arm rotates horizontally and has a 36mm hex axle with an axle locking handle.
• Powerful tyre-pressing knife - up to 2700 kg of pressing power is developed
• Tire inflation gun with monometer - for convenient and fast tire inflation and pressure check.

Technical parameters:

• Inner rim clamping diameter: 12" - 24"
• Outer rim clamping diameter: 10" - 22"
• Maximum wheel diameter: 960 mm
• Maximum wheel width: 3" - 15" | 76 - 380 mm
• Tire pressure: 2700 kg (27000 N)
• Working pressure of the machine: 8 - 10 bar
• Motor power: 1.1 kW
• Machine supply voltage: 230 V / 50 Hz / 1fz

Standard equipment:

• Bucket for tire mounting paste x 1 pc.
• Tire mounting paste brush x 1 pc.
• Mounting head plastic protection x 1 pc.
• Bead breaker protection x 1 pc.
• Gripper plastic protection x 4 pcs.
• Mount lever x 1 pc.
