Automatic tire changer BD-860 + BD-215

Automatic Tire Mounting Machine BD-860 + BD-215

Features:

• Steel mounting head – durable construction with replaceable plastic protectors to prevent rim damage.
• Self-centering clamps – secure rim fixation using two pneumatic cylinders.
• Independent tire inflation system – includes a pressure gauge, inflation hose, and inflation button.
• Pneumatic mounting head locking – the head position can be easily adjusted using a foot pedal and locked in place with a single button press.
• Filter and pressure regulator system – ensures optimal air supply and protects the equipment from moisture.
• Auxiliary tire mounting arm – facilitates work with complex rims and includes bead pressing rollers, a lifting disc, and a bead pressing head.

Technical Specifications:

• Clamping inner rim diameter: 15" – 28"
• Clamping outer rim diameter: 13" – 26"
• Maximum wheel diameter: 1200 mm
• Maximum wheel width: 3" – 15" | 76 – 380 mm
• Bead breaker force: 2700 kg (27000 N)
• Operating pressure: 8 – 10 bar
• Mounting speeds: two
• Motor power: 1 kW
• Power supply: 380 V / 50 Hz / 3-phase

Standard Accessories:

• Tire mounting paste bucket x 1 unit
• Tire mounting paste brush x 1 unit
• Plastic protector for mounting finger x 1 unit
• Plastic protector for bead breaker blade x 1 unit
• Plastic protectors for clamps x 4 units
• Mounting lever / bar x 1 unit
