Automatic air conditioning service station for hybrid systems BD-093

Automatic Air Conditioning Service Station for Hybrid Systems BD-093

Features:

• Fully automatic operating mode
• Designed for servicing A/C systems in hybrid vehicles
• Refrigerant recovery, vacuuming, oil injection, and charging
• Integrated POE oil container (for electric systems)
• Equipped with a heating belt, cooling fan, and condensate filter
• Automatic maintenance reminder
• Built-in database with free updates
• High-quality pump and pipe system
• Easy operation via 7-inch touch screen

Technical Specifications:

• Power supply: 230 V / 50 Hz / 1 phase
• Display: 7" touch screen
• Refrigerant type: R-134a
• Compressor power: 3/8 HP
• Recovery efficiency: ≥96%
• Average refrigerant recovery speed: 0.25 kg/min
• Vacuum pump capacity: 60 l/min
• Refrigerant tank capacity: 10 kg
• Refrigerant charging accuracy: ±10 g
• New oil container: 250 ml
• Used oil container: 400 ml
• Oil dosing accuracy: ±5 g
• Dryer filter capacity: 600 ml
• Maximum working pressure: 20 bar
• High pressure gauge range: -1 to 30 bar
• Low pressure gauge range: -1 to 16 bar
• Maximum refrigerant charging speed: 2 kg/min
• Weight: 88 kg
• Dimensions: 600 x 600 x 1050 mm
• Package dimensions: 710 x 690 x 1180 mm
