AC Hydraulic GD200-2 Double Pneumatic Hydraulic Pit Hoist 20t

Double pneumo-hydraulic pit jack AC Hydraulic GD200-2 20t

Country of origin: Denmark, warranty period – 3 years for hydraulics and 10 years for frame components

Pneumo-hydraulic pit jack with two cylinders, designed for lifting trucks in workshops or service centers. Ensures safe, synchronized lifting and easy adaptation to different needs thanks to the adjustable frame height.

Functions:

• Fast and precise lifting with high-speed cylinder
• 2 independently controlled cylinders for safe and parallel lifting
• Modern design with ergonomic working height
• Adjustable frame height
• Movable cylinders for wider application
• Suitable for use with cross beams, support bridges, etc.
• Supplied with 2 x 100 mm extensions

Technical specifications:

• Lifting capacity: 20 tons
• Stroke: 420 mm
• Minimum height: 545 mm
• Maximum height: 945 mm
• Lift length: 590–890 / 850–1150 / 1110–1410 mm
• Lift width: 649 mm
• Required air pressure: 8–12 bar
• Required air flow: 350 L/min
• Weight: 220 kg
