Vacuum blasting booth Venturi type PAL3-L Sabbiatrici

Vacuum blasting booth Venturi type PAL3-L Sabbiatrici

Country of origin: Italy, warranty period - 24 months

Possible additional modifications and various accessories are available upon request

The PAL3-L vacuum-type blasting and shot peening booth is designed for various surface treatment tasks such as shot peening, decorative sandblasting, metal hardening, cleaning, polishing, and other technical surface preparation operations. By using different types of abrasives (corundum, sand, glass microspheres, synthetic or vegetable granules, metal abrasives), this booth enables efficient processing of various components. It can be optionally equipped with a dust filtration system, loading cart, rotary table, or abrasive regeneration cyclone. If needed, the booth can be converted into a pressure system, allowing for even more efficient and precise operation.

Functions:

• Suitable for shot peening, sandblasting, hardening, finishing, and cleaning
• Compatible with various abrasives – from corundum to glass microspheres or metal granules
• Convertible from vacuum to pressure system
• Optional accessories: dust collection system, rotary table, loading cart, regeneration cyclone
• Suitable for working with aluminum, iron, glass, stainless steel, etc.
• Enables deep engraving or light polishing
• Protects workpieces from mechanical damage

Technical specifications:

Internal dimensions:

• Front – 1180 mm
• Side – 800 mm
• Height – 780 mm

External dimensions:

• Front – 1220 mm
• Side – 1260 mm
• Height – 1900 mm

Booth access: side, from both left and right

• Dust extractor: 400 V, 50 Hz, 0.75 kW
• Lighting: LED 20 W

Air consumption:

• Injector ∅ 3 mm – 600 l/min
• Injector ∅ 3.5 mm – 800 l/min
• Injector ∅ 4 mm – 1200 l/min
• Operating pressure: from 1.5 to 8 bar
• Tungsten carbide nozzle: ∅ 6, 8, or 10 mm
• Weight: 180 kg
