Universal commercial vehicle diagnostic equipment JalTest CV

Universal commercial vehicle diagnostic equipment JalTest CV

JalTest CV diagnostic package - a universal diagnostic device that is used for trucks, buses, minibuses, trailers diagnostics. JalTest diagnostic equipment is one of the best solutions for working with trucks and other commercial vehicles. The diagnostic equipment connects to the computer via a USB cable or wireless connection. The leading universal diagnostic tool for commercial vehicles with the widest coverage on the market. The coverage of the device includes all European, American, Asian and other models of trucks, buses, minibuses.

We recommend choosing the official Jaltest truck diagnostic tool for the following reasons:

• Not sure if it will meet your needs? To prove this, before purchasing, we let our customers try Jaltest devices and it costs nothing - you will feel the advantages of official equipment!
• Jaltest software, compared to competitive analogues, is constantly updated, its latest technical manuals and databases are expanded. Therefore, with a Jaltest device, your range of work and the functionality of the device is much greater.
• Jaltest has the latest database, including Euro 6 support! Compared to other diagnostic devices, you will not experience any software crashes, hardware or device failures or failure to support the latest standards.
• Jaltest has the fastest technical support, online help, warranty and post-warranty repair compared to competitors.

Technical characteristics:

• Connects to a stationary or portable PC via Bluetooth interface or USB cable
• Bluetooth operation: 20-50 years
• Minimum requirements for PC: DVD reader, Windows XP, 7, 8, 10 64-bit OS, 2 Gb RAM, 10 Gb free hard disk space, USB connection
• Power supply via OBD connector or 12/24 V DC power supply unit
• Used electric power: 7W
• Impact resistant body
• Weight: 1.2 kg
• Dimensions: 183 x 131 x 56 mm
• Operating temperature: from 0°C to +45°C
• Multilingual menu
• Certificates: CE, FCC, RoHs

Features of diagnostic equipment:

• For trucks, buses, passenger and cargo minibuses, pickups, semi-trailers
• All commercial transport standards and protocols are supported, including RP1210 and Pass-Thru
• Intuitive and fast software interface
• Automatic detection of systems and errors
• Troubleshooting by symptoms and errors
• Integrated technical information, electronic diagrams, technical documents
• ETM - electronic test module
• GRP - workshop resource planning
• Suitable for all makes of commercial vehicles
• Repair times
• It can also be purchased separately for each brand of commercial vehicle.

Equipment features and application possibilities:

• Diagnostics of electronic control units (EVB) via the OBD interface or a specific adapter
• Ability to connect to any diagnostic connector using a universal diagnostic cable with special tips
• Integrated automatic multiplexer - automatic switching of K and L, CAN, SAE lines to any OBD connector terminal
• Support of diagnostic protocols: ISO 9141-2, K/L lines; ISO 14230 (KWP2000), K/L lines; SAE-J1850 VPW and PWM; ISO 11519-2; SAE J1708; ISO 15765-4 (OBD); CAN ISO 11898; CAN (High Speed, Middle Speed, Low Speed, single-wire CAN system support); SCI Haldex; RP 1210; SAE J2534 (PASS-THRU).
• Component activation: the ability to send signals to various systems using Jaltest, such as fan activation, cylinder deactivation, compression measurement and operation of different mechanisms
• Up to 8 values ​​are measured and displayed at the same time / information about nominal value ranges

Standard equipment:

• JALTEST PC LINK interface
• OBD cable JDC213M3
• USB cable JDC107.4
• Suitcase 29380
• Universal diagnostic cable with a set of special tips JTP96
• Power cables from the battery and from the vehicle power outlet

Additional equipment:

• Cable set for truck and bus diagnostics (8 units) (Volvo; Mercedes Benz; Scania; Renault; Iveco > 1998; MAN- TGA, TGL, TGM; DAF; MAN F2000)
• Thermoking diagnostic cable COJALI JDC113A
• Software JalTest Soft + INFO Online for diagnostics of trucks, trailers, buses and minibuses
• Annual (12-month) renewal subscription for JalTest Soft + INFO Online software
• Program package for diagnostics of trucks and tractors
• Program package for bus diagnostics
• Program package for diagnostics of minibuses and commercial cars

Supported truck brands: DAF; MAN; VOLVO; ISUZU; IVECO; RENAULT; MERCEDES-BENZ; SCANIA; CATERPILLAR; FORD; TATA; TATRA; AGRALE; ASHOK LEYLAND; ASKAM; ASTRA; AVIA; BEIBEN; BHARATBENZ; BMC; CAMC; CAPACITY; CNHTC-SINOTRUK; DENNIS EAGLE; DONGFENG; EICHER; ERF; FAW; FODEN; PHOTON; FREIGHTLINER; GAS; HAOHAN; HINO; HYUNDAI; ; JAC; KAMAZ; KENWORTH; MACK; MAHINDRA; MAZ; MITSUBISHI FUSO; NISSAN; OSHKOSH; PETERBILT; SAIC-IVECO HONGYAN; SEDDON ATKINSON; SHACMAN; SISU; SML ISUZU; STERLING; TATA-DAEWOO; TERBERG; UD TRUCKS; URO; VOLKSWAGEN; VOLVO USA; WESTERN STAR.

Supported bus brands: ISUZU; IVECO/IRISBUS; MAN; MERCEDES-BENZ; VOLVO; MAZ; SCANIA; NEOPLAN; SOLAR; AGRALE; ALEXANDER DENNIS; ASHOK LEYLAND; AUTOSAN; BCIs; BHARATBENZ; BLK; BLUE BIRD; BMC; BELIEVE; DAEWOO; DINA; EICHER; FORCE MOTORS; FORD Custom Chassis; FREIGHTLINER Custom Chassis; GILLIG; GOLDEN DRAGON; HIGER; HINO; HYUNDAI; IC (INTERNATIONAL); IRIZAR; KARSAN; KING LONG; MAHINDRA; MCI; MCV; ARTISTIC; ITSUBISHI FUSO; NABI; NEFAZ; NEW FLYER; NOVA BUS; ORION; OTOKAR; PREVOST; RENAULT; SETRA; SML ISUZU; SOLBUS; SOR; TATA; TEMSA; THOMAS BUILT; TOYOTA; VAN HOOL; VDL; VISEON WILL; VOLKSWAGEN; WRIGHTBUS; YUTONG; ZHONGTONG.

Supported minibus brands: ISUZU; MAN; MERCEDES-BENZ; RENAULT; TOYOTA; GAS; FIAT; CITROËN; FORD; HYUNDAI; NISSAN; PIAGGIO; IVECO; VOLKSWAGEN; AGRALE; ASHOK LEYLAND; BAW; DODGE; FORCE MOTORS; PHOTON; FREIGHTLINER; GMC / CHEVROLET; GREAT WALL; HINO USA; HOLDEN; INTERNATIONAL; ISUZU USA; KIA; LDV; MAHINDRA; MAZDA; MITSUBISHI; MITSUBISHI FUSO USA; MULTICAR; OPEL; PEUGEOT; SANTANA; TATA; UD TRUCKS; VAUXHALL.

Supported semi-trailer brands: BENDIX; CARRIER; CHEREAU; COJALI; DANA; HALDEX; KNORR-BREMSE; THERMO KING; VIGIA; WABCO.

You can find support for manufacturer models here: https://www.jaltest.com/en/coverage/
