Ultrasonic tank 1000 liters with lifting platform and filtration system AL-1000 SONIXTEC

Ultrasonic tank 1000 liters with lifting platform and filtration system AL-1000 SONIXTEC

Country of origin: Belgium, warranty period - 24 months

The industrial ultrasonic tank AL-1000 from the SONIXTEC AL series is designed for demanding industrial use where powerful and deep cleaning is required. The unit is equipped with an automated pneumatic lifting platform that allows easy loading and unloading of parts, while the agitation function improves cleaning efficiency. The operation is managed through a 7-inch touchscreen, and the entire system is controlled by a Siemens PLC controller. The AL series tanks feature a robust construction, advanced cleaning functions, and an integrated laminar flow and filtration system with oil separation.

Functions:

• 7-inch touchscreen
• Siemens PLC 8xI 6xO control system
• 8 programmable automatic cleaning cycles
• Thick-walled tank made of stainless steel AISI 304
• External panels made of stainless steel AISI 304
• Submersible transducer boxes made of stainless steel 316L
• Reinforced pneumatic platform with agitation function up to 2000 kg
• Laminar flow system and filtration system with oil separation
• Adjustable heating from 30 °C to 100 °C
• Digital generator for more efficient cleaning
• Sweep, Degas, Pulse, and Dynamic cleaning modes
• Compressed air gun
• Insulated lid with diamond-shaped drip collection system (optional automatic lid)
• Sloped tank bottom for easy cleaning
• Lockable castor wheels and vibration-dampening feet
• 1" water inlet ball valve and 1" drainage connection
• Adjustable leveling feet
• Emergency stop switch and main power switch

Benefits:

• Time-saving – ultrasonic tanks quickly and effectively remove contaminants
• Wide range of contaminant removal – cleans various materials, surfaces, and parts
• Deep cleaning – removes dirt even from microscopic crevices
• Gentle on surfaces – cleans without friction or scrubbing
• Low energy consumption – efficient use of electricity and transducers
• Environmentally friendly – reduces the use of hazardous solvents and overall energy consumption

Technical specifications:

• Model: AL-1000
• Capacity: 1000 liters
• Tank dimensions: 150 x 81 x 87.5 cm
• Useful tank dimensions: 138 x 68 x 50 cm
• External dimensions: 262 x 138 x 209 cm
• Maximum load capacity: 750 kg
• Power supply: 3-phase, 400V
• Heating power: 18000 W
• Ultrasonic power: 12000 W
• Working frequency: 28 kHz or 40 kHz
• Number of ultrasonic transducers: 200
• Tank material: stainless steel AISI304, 2.5 mm
• Weight: 950 kg

Applications:

• General workshops
• Diesel injector workshops
• Grinding workshops
• Turbocharger repair workshops
• Engine repair and rebuilding
• Gearbox repair workshops
• Marine industry
• Heavy machinery service
