Turbine core balancing equipment CIMAT CMT-48 VSR Big Twin

Turbine core balancing equipment CIMAT CMT-48 VSR Big Twin

Manufacturer CIMAT (Poland), warranty 12 months.

The CIMAT CMT-48 VSR is state-of-the-art equipment designed to perform the most accurate turbine repair operations possible, which is extremely accurate, efficient and easy to use. These machines consist of two sets of accessories to balance the turbine cores of not only cars but also trucks. CIMAT has developed an energy-saving adapter system consisting of a plate and a bushing for its VSR equipment line. The plate attaches the core bearing housing to the machine and the bushing drives the turbine wheel with compressed air.

Adapter system:

Different turbochargers mean different dimensions - bearing housings and rotors can be of different sizes. This means that if you use a single-cell adapter, you will have to buy new adapters for almost every CHRA. The CIMAT two-element adapter can be used in pairs, so it can come in a variety of configurations. Different configurations mean fewer adapters. Fewer adapters mean less overhead.

With this adapter system developed by CIMAT, 10 plates and 10 special bushings are equivalent to 100 traditional adapter configurations that you would have to buy if you used a machine from another manufacturer. In addition, each plate and each bushing is universal and fits up to a dozen bearing housings and rotors - meaning fewer adapters will work with more assemblies. This innovative solution saves your company time and money.

Unique features:

The technology is recognized worldwide

Core oil leakage tests

Balancing speed - up to 300,000 rpm

Oil temperature and pressure control to prevent the turbine from drying out

Space-saving equipment

Automatic air control valve

Energy and cost saving adapter system

Adapter replacement time is less than 30 s.

Five-stage oil filtration system

Free warranty and post-warranty remote technical online support

The balancing interface is available in almost all languages

ISO 21940-23: 2012 (old: ISO 7475 DIN 45690)

Safety protection with safety interlocks and CE mark

Technical features for truck core balancing:

Balancing speed (depending on turbine model): ≤ 40,000 rpm

Minimum achievable residual imbalance in one plane: 0.05 gmm

Maximum core weight: 16 kg

Turbine wheel diameter: ≤ 130 mm

Number of balanced planes: 2

Technical features for balancing car cores:

Balancing speed (depending on turbine model): ≤ 300,000 rpm

Balancing Results: Graph G

Max. turbine wheel diameter: 85 mm

Number of balanced planes (two plane correction possible): 1

Technical features of the machine:

Power supply: 230 V +/- 10%, 50/60 Hz

Machine weight: 550 kg

Dimensions: 1450 x 1050 x 1600 mm

Required air hose diameter: 1.25 "

Required air compressor pressure: 8 bar

Required air tank volume: 1 m3
