To meet the needs of customers who work with large volumes of washing liquids or coolants, Marwis introduces its innovative product to the market: the high-performance lamellar oil separator, the Oil Skimmer.

Perfect for places where high oil contamination greatly shortens the life of the washbasin. This is virtually irreplaceable when washing large bags, where the cost of manufacturing and disposing of the bath accounts for a large proportion of the surface treatment costs.

The second industry in which the OIL Skimmer will be used is high-performance machining. When every minute of machine downtime is significant, extending the interval between coolant changes means a measurable financial benefit.

In the opinion of the oil separator, it is the separation of the oil in the washing liquid or coolant. The process begins in a tank where greasy contaminants float on the surface of the bath. Ypac

the designed draft of the oil separator collects only the top layer of liquid. The pump forces the collected liquid through filters that trap solid contaminants such as chips.

The filtered liquid enters the main chamber of the oil separator, where, depending on the application, the oil is separated from the washing liquid or coolant using the fusion principle.

The separated oil enters a specially prepared container and the liquid returns to the circulation. The efficiency of the process is very high - the oil separator is able to collect more than 99% of the oil.

To make the most of the application, the OIL SKIMMER oil separator has two types of tows - one floats on the surface of the bath and the other is magnetically attached to the tank of the controlled machine.

Long connecting hoses ensure comfortable work - no need to place the oil separator directly next to the machine - it can be conveniently located.

The intuitive control panel makes operation easy. A convenient switch can be switched even when wearing gloves. A built-in pressure reducer with a readable pressure gauge allows the control of various pneumatic pumps. A safety switch that meets the standards will stop in the event of a process failure or other hazardous situation, such as a fluid leak.

Technical specifications:

Dimensions: 1050mmx580mmx1070mm

Weight: 95 kg

Capacity: 150-450l / h

The acceptable pH range is: pH 1-14

Air pressure: 3-6 bar

Operating temperature: <60 ° C

Canister for separated oil: 25 L
