Mobile scissor lift (metric) ATH-Flex Lift 30Z
Mobile, galvanized medium lift with mechanical synchronization, which is connected to the pavement.
Country of origin: ATH-Heinl (Germany); Warranty 36 months
Description:
- Mobile medium lift with repositioning kit
- Lift suitable for painting and body work, brake and tire service. Using little space.
- Galvanized (ATH-Flex Lift 30Z: 680008-FZ) or powder coated (ATH-Flex Lift 30: 680008)
- No electrical limit switches, no problems with possible moisture or direct water ingress
- Easy to operate; can be built on any floor and plain ground without any fixing work
- Dual hydraulic cylinder system with hydraulic earthing protection does not require any additional air or compressor connection
- Fast lifting from the ground
- Mechanical synchronization with cross connection on the ground
- The mobile 230 V control module is easy to move and install where convenient
- Reinforced hoses protect the hydraulics from damage
- Possibility to extend platforms with additional equipment
Technical parameters
- Maximum load: 3000kg
- Lifting height: 100 - 960 mm
- Lifting speed with load: 21s
- Release speed with load: 21s
- Lifting platform length: 1450 - 2030 mm
- Width of the lifting platform: 530 mm
- Mobility: Yes
- Lifting engine power: 1.5 kw
- Power supply / frequency: 230 V / 50Hz
- Short circuit protection: C16 A
- Oil content: 10 liters
- Weight: 590 kg
Length: 1200 mmHeight: 850 mmWidth: 600 mm
