Drilling and mortising machine Holzmann LBM250C_400V

Drilling and mortising machine Holzmann LBM250C_400V

Country of origin: Austria, warranty period - 24 months

The Holzmann LBM250C_400V is a robust grey cast iron drilling and mortising machine designed for highly precise and professional woodworking tasks. Thanks to its rigid construction and versatile adjustment options, the machine is ideal for drilling complex holes, including angled and precision bores. The included accessories and convenient control system allow for quick, accurate, and safe operation in both transverse and longitudinal directions.

Functions:

• Stable, torsion-resistant grey cast iron construction for precise work
• Easy execution of angled and precision bores
• Drilling head pivotable to the left and right
• Convenient one-hand operation
• Large working range
• Pin drilling device with four preset distances (16–22–25–32 mm)
• Adjustable stops for transverse and longitudinal operation
• Easy height adjustment via handwheel
• Integrated phase switch
• Included accessories: mitre gauge, 2 eccentric clamps, Wescott-type drill chuck 0–20 mm, motor protection, extendable table, pin drilling device

Technical specifications:

• Motor power S6: 3100 W
• Motor power S1: 2200 W
• Voltage: 400 V
• Table stroke: 155 mm
• Table dimensions: 600 x 320 mm
• Max. drilling width: 250 mm
• Pin hole distances: 16 / 22 / 25 / 32 mm
• Max. drilling depth: 215 mm
• Net weight: 205 kg
• Gross weight: 240 kg
• Packaging dimensions (H x W x L): 1260 x 740 x 1000 mm
