Laser welding machine 3000W

Laser welding machine 3000W

A laser welding machine ensures unrivaled quality seams. This device is superior to traditional welding methods such as MIG or TIG, because it offers exceptional precision. The laser allows for much smaller microscopic weld seams, which in turn reduces the thermal influence zone on the environment. As a result, laser welding is an excellent choice for joining even very small parts that are difficult to join with other welding methods. This laser is used not only for welding, but also for cutting and cleaning various materials. Laser cutting allows for precise separation of materials, creating precise and clean edges without mechanical processing. The cutting function as an additional device option allows you to cut stainless steel up to 2 mm and carbon steel up to 1.5 mm. Copper and aluminum are highly reflective materials and should not be cut with a laser. Laser cleaning is an effective way to remove dirt, paint layers or rust from the surface of materials, while maintaining their surface integrity and quality. Thanks to these applications of laser technology, we achieve exceptional efficiency in processing materials with minimal impact on their structure.

Advantages of a laser welding machine:

• High welding accuracy
• Excellent welding process control
• Less material deformation
• Clean welds that do not require processing
• Suitable for use in hard-to-reach places
• Optimized working time
• Durable welds
• Can be used for joining, cutting and cleaning various materials
• High-class laser source

Wire feed mechanism:

The wire feed mechanism of a laser welding machine is a device that accurately feeds the welding material to the welding site. This is important for controlling welding parameters, improving the quality of welds and increasing process efficiency. It automates wire feeding, so the operator can concentrate on maintaining the welding process.

Weldable materials:

• Stainless steel: 8 mm
• Galvanized sheet: 6 mm
• Iron: 8 mm
• Mild steel: 8 mm
• Aluminum: 5 mm

Technical parameters:

• Power: 3000 W
• Wavelength: 1070 Nm
• Hose length: 10 m
• Power supply: 400 V
• Power consumption: 10 kW
• Frequency: 50/60 Hz
• Current: 29 A
• Laser head (gun) operating modes: lines / points / oscillations, waves
• Positioning: red dot
• Gun weight: 760 g
• Focusing length: 150 mm
• Welding speed: 0-230 mm/s
• Drying system: distilled water
• With touch screen
• Wire feed: automatic with return
• Wire diameter: 0.8,1.0,1.2,1.6 mm
• Gun blow pressure: up to 15 bar
• Languages: Polish, English, German, French, Spanish, Italian, Czech, Slovak, Greek, Romanian, Portuguese, Korean, Turkish, Russian
• Dimensions: 840 x 595 x 1080 mm
• Weight: 220 kg

Complete set:

• 10 pcs. protective lenses
• Set of copper tips
• Safety glasses
• Funnel
• Laser cable
• Grounding kit
• Lens replacement tool kit
• Raycus/Max power source (optional)
• Refrigerator
• Cleaning gun
