Electronic light adjustment bench WT Engineering PH2010

Electronic light adjustment bench WT Engineering PH2010

Manufacturer WT-Engineering (Italy)

Description:

The values ​​can be measured on the lamp adjustment bench with a camera.

Low beam values: vertical = +2% to -4%; horizontal = +3 ° to -3 °, brightness = 150 Klux 1m

High beam values: vertical = +3% to -3%; horizontal = +3 ° to -3 °, brightness = 150 Klux 1m

Fog lights: vertical = +2% to -4%; horizontal = +3 ° to -3 °, brightness = 150 Klux 1m

Three management methods: overview, management and trial. 230 mm lens, optical camera laser centering and longitudinal alignment. The test stand is suitable for optical incandescent bulbs, xenon, LED bulbs.

Technical data:

Measuring height: 250 - 1500 mm.

Lens diameter: 230 mm

Measured light intensity: 0 - 150 Klux 1 m.

Dimensions: 600 x 700 x 1700 mm

Weight: 38 kg

Available options:

PH2010G electronic lamp adjustment stand. Rotating column, 230 mm Fresnel beam, laser lines and laser point positioning, mobile screen and microprocessor for electronic regulation RS 232.

PH2010INT electronic lamp adjustment stand. Rotating column, 230 mm Fresnel, laser lines and laser point positioning, mobile display and microprocessor electronic control software.

PH2010KAM (camera): Electronic lamp adjustment stand with camera. Rotating column, 230 mm Fresnel beam, laser lines and laser point positioning, mobile screen and microprocessor for electronic adjustment, 7-inch touch screen.

Prices with VAT:

PH2010G = EUR 1270.00 including VAT

PH2010INT = EUR 1220.00 including VAT

PH2010KAM (camera) = 2280.00 EUR with VAT

Additional ordered goods, price including VAT:

For these stands, 4 meter long rails with screws and necessary pins can be ordered for EUR 180.00 including VAT

230 mm glass fund = EUR 160.00 including VAT

Printer = EUR 215.00 including VAT

SLS (self-adjusting system) ordered for PH2010KAM = EUR 520.00 including VAT
