Electrohydraulic 2-post lift with asymmetrical support arms for cars and vans

Made in Germany;

Description:

fully automatic lifting and lowering at the touch of a button

The short brackets are double telescopic to accommodate short to very long vehicles

Door protection rubbers on both columns

Column cover in both lifting columns for protection against contamination

asymmetric support arms for large door opening angles

Carrying plate with rubber pad, with double height adjustment by turning

a set of support plate heights (4 pieces a 100 mm) included

Maintenance and wear-resistant, thus low follow-up costs

easy handling by 24 volt safety button control (deadman control)

ideal pick-up area for cars and also suitable for vans due to its large clearance

automatic, conically fine-toothed support arm lock, manual unlocking possible

standing lifting cylinder in both columns, sealing of the hydraulic cylinder takes place in the cylinder tube, thus no risk of damage (soiling, grinding or welding spatter, etc.) on the piston rods

multiple safety device, overload valve, pipe rupture protection and mechanical safety pawls

Hose guide in the column (pre-assembled on the control column)

simple design, as many attachments (motor, control box, hose to control column, etc.) are already pre-assembled

Safety pawls electromechanically actuated

permissible load capacity 4500 kg, the structure of the lift has been successfully tested dynamically with a load of 115% of the gross vehicle weight and statically with 150% of the gross vehicle weight

Floor requirement according to current (permissible in Germany) statics, concrete C20 / 25 DIN1045: 2001-D7 double armored with an extension of min. 4000 x 2000 x 200 mm
