Dust Collector for Workshops

Dust Collector for Workshops ABS850

Country of Origin: Austria, warranty period - 24 months

The dust collector is a compact and powerful device designed for removing dust and wood chips in workshops. It is mobile, operates quietly, and is easy to use. The included suction hose allows efficient waste collection, while the metal impeller ensures durability and long-lasting performance.

Features:

• High performance with minimal space requirements.
• Mobile and quiet operation.
• Includes a 2-meter suction hose.
• Metal impeller ensures reliable operation.

Technical Specifications:

Motor Data:

• Motor Power S1: 750 W.
• Motor Power S6: 1050 W.
• Voltage: 230 V / 50 Hz.

Dimensions:

• Dust Collector Port Diameter: Ø 100 mm.

Dust Collection:

• Suction Performance: 850 m³/h.
• Chip Bag Capacity: 40 l.
• Chip Bag Diameter: 280 mm.
• Chip Bag Length: 900 mm.
• Fan Wheel Diameter: 230 mm.
• Hypotension: 800 Pa.

Noise and Vibration Levels:

• Sound Power Level: 78 dB(A).
• Sound Pressure Level: 76.6 dB(A).

Weight:

• Net Weight: 23 kg.
• Gross Weight: 26 kg.

Packaging:

• Height: 410 mm.
• Width: 450 mm.
• Length: 760 mm.
