Diesel Generator FN-125

Diesel Generator FN-125

Country of Origin: Turkey, warranty period - 24 months

The Diesel Generator FN-125 is a reliable and efficient solution for electricity supply in industrial, commercial, and other demanding projects. The generator features a YANGDONG heavy-duty diesel engine with an electronic control system and water cooling, ensuring stable performance even under full load conditions. It is equipped with a soundproof canopy and a modern chassis, reducing noise levels and facilitating transportation.

Features:

Engine:

• FN-125 heavy-duty diesel engine.
• 12V starter and charging alternator.
• Replaceable air, fuel, and oil filters.
• Mechanical control system.
• Tropical-type radiator and flexible fuel hoses.
• Oil drain valve with extension hose.
• Industrial silencer and steel compensator.
• Maintenance-free battery.
• Water jacket heater.
• Soundproof Canopy and Chassis:
• Convenient design for easier transportation.
• High-standard soundproof canopy.
• Modular design with easily removable bolts.
• Lockable doors.
• Transparent window for monitoring the control panel.
• Electrostatic powder coating, resistant to harsh weather conditions.
• Emergency STOP button.
• Fuel tank integrated into the chassis.
• Anti-vibration wedges between the engine, chassis, and ground.

Generator:

• IP21-23 protection standard.
• H insulation class.
• 50 Hz frequency.
• 4-pole brushless synchronous generator.
• Automatic Voltage Regulator (AVR).
• 400/230 V AC output voltage.

Technical Specifications:

Engine:

• Engine model: YD4GZLD.
• Number of cylinders: 4 inline.
• Injection system: Direct.
• Compression ratio: 18.
• Displacement: 4.4 liters.
• Turbocharging: With intercooler.
• Speed: 1500 rpm.
• Oil capacity: 12 liters.
• Cooling system capacity: 15.1 liters.
• Maximum power: 99 kW / 113 hp.
• Prime power: 90 kW / 121 hp.
• Fuel consumption:
• Full load: 17.9 l/h.
• 75% load: 13.6 l/h.
• 50% load: 9.2 l/h.

Generator:

• Power output: 132 kVA.
• Voltage: 400 V.
• Frequency: 50 Hz.
• Insulation class: H.
• Protection standard: IP23.
• Power factor: 0.8.

Dimensions and Weight:

• Weight (silent type): 1250 kg.
• Weight (open type): 1050 kg.
• Dimensions (silent type): 1000 x 2800 x 1500 mm.
• Fuel tank capacity: 220 liters.
