Bus diagnostic equipment Jaltest PC Link

Bus Diagnostics Tool – Jaltest PC Link

Warranty period – 24 months

Why Choose Jaltest PC Link?

• Designed for the Bus Segment
• Optimized for diagnostics of city, intercity, and school buses with broad support coverage.
• Works Anywhere – In the Workshop or in the Field
• Wireless connectivity allows diagnostics to be performed on-site – no need to limit work to the workshop floor.
• Intuitive Software Interface
• A user-friendly interface allows quick access to required data, error analysis, and system checks.
• One Tool for All Connections
• Thanks to a universal cable and adapter set, the device adapts to any connector type.
• Technical Support and Expandability
• Easily expand the system with new modules and benefit from technical assistance and software updates.

Functions:

• ECU (Electronic Control Unit) diagnostics via OBD interface or specific adapter
• Ability to connect to any diagnostic port using a universal diagnostic cable with special adapters
• Integrated automatic multiplexer – automatic switching of K and L, CAN, and SAE lines to any OBD terminal
• Supported diagnostic protocols: ISO 9141-2, K/L lines; ISO 14230 (KWP2000), K/L lines; SAE J1850 VPW and PWM; ISO 11519-2; SAE J1708; ISO 15765-4 (OBD); CAN ISO 11898; CAN (High Speed, Medium Speed, Low Speed, single-wire CAN); SCI Haldex; RP 1210; SAE J2534 (PASS-THRU)

Technical Specifications:

• Connects to a desktop or laptop PC via Bluetooth or USB cable
• Bluetooth range: 20–50 m
• Minimum PC requirements: DVD drive, Windows XP, 7, 8, 10 (64-bit OS), 2 GB RAM, 10 GB free HDD space, USB port
• Powered via OBD connector or 12/24 V DC power supply
• Power consumption: 7W
• Shock-resistant housing
• Weight: 1.2 kg
• Dimensions: 183 x 131 x 56 mm
• Operating temperature: 0°C to +45°C
• Multilingual menu
• Certifications: CE, FCC, RoHS

Standard Kit Includes:

• JALTEST Modular Bus software 293300
• Jaltest Modular Bus license 29051300

Optional Add-ons:

• Diagnostic cable kit for trucks and buses (8 pcs): Volvo; Mercedes-Benz; Scania; Renault; Iveco > 1998; MAN – TGA, TGL, TGM; DAF; MAN F2000
• Thermo King diagnostic cable COJALI JDC113A
• JalTest Soft + INFO Online software for truck, trailer, bus, and van diagnostics
• JalTest Soft + INFO Online 12-month update subscription
• Diagnostic software package for trucks and tractors
• Diagnostic software package for vans and light commercial vehicles

Who Is This Device For?

• Jaltest PC Link is intended for professional bus service centers, maintenance technicians, and independent diagnostic specialists working with minibuses and passenger transport. It is a tool for quickly and accurately identifying problems, calibrating systems, and ensuring efficient vehicle operation.

Your job – our solution. Reliable diagnostics start with Jaltest!

• Contact us for a live demo or try Jaltest PC Link in your own workshop – and see how simple it is to have everything in one solution.
