Large electric powder coating furnace COLO 1645

Large electric powder coating furnace COLO 1645

• A 4.5 meter long curing oven is designed to powder coat large parts or a large batch of small parts.
• Electric heating reduces operation and maintenance costs and also creates a cleaner environment.
• COLO powder coating furnaces are made of high quality components that ensure fast and even heating.

Powder coating furnace trolley systems

• Powder coating furnaces are equipped with two trolleys as standard, including an upper and a lower trolley.
• With two trolleys, the trolleys running through the hall do not contaminate the inside of the oven.
• It is an inexpensive manual transport system that allows you to carry heavy elements with low force and optimizes the use of the entire surface with high temperature bearings.

Electrical properties of a powder coating furnace

• It is easy to operate thanks to the PLC control unit with precise temperature and time control.
• 100 mm thick stone wool insulation material maintains a constant temperature with a stability of less than 3 ℃.
• The high-level fan is perfect for circulating hot air, reaching any corner of the oven to ensure evenness.
• Built of high efficiency electric heating elements ensures a rapid rise in temperature.
• Sizes can be selected from our standard models and can also be customized as needed.

Technical data:

• Voltage: 380 V / 220 V
• Frequency: 50-60 hz
• Warm-up time: 15-30 min. (180 ° C)
• Temperature stability: <± 3-5 ° C
• Maximum temperature: 250 ° C
• Ventilation efficiency: 1131-2565 m3 / h
• Engine power: 3 kw
• Circulation / air flow vertically: variable through holes in the walls
• Dimensions of working size: width 1500 mm, height 1650 mm, depth 4500 mm
• Overall dimensions: width 1800 mm, height 2050 mm, depth 4800 mm
