Autel smart electricity meter, single-phase

Autel smart electricity meter, single-phase

Manufacturer: Autel, Germany

Autel Smart Meter 1F AC is a universal electricity meter that is suitable for single-phase electricity networks. The meter is adapted to withstand electric current up to 100 A and is easily mounted on standard DIN rails. It can measure and display 1-phase electric current parameters. Simple and intuitive control, equipped with remote data reading.

Features:

• MID Certified (B and D)
• 100 A single phase input
• Four kWh measurment modes for PV and battery storage
• Built in Modbus and pulsed outputs or optional Mbus interface
• Simple menu navigation
• Two module DIN rail mounted
• Highly visible backlit display

Displayed parameters:

• Phase to Neutral Voltage (V
• Phase Current (A
• Frequency (Hz
• Power Factor ( PF)
• Power max demand (MD kW)
• Active power (kW)
• Reactive power (kVAr)
• Apparent power (kVA)
• Import active power (kWh)
• Export active power (kWh)
• Total active power (kWh)
• Imprt reactive power (kVAh)
• Export reactive power (kVAh)
• Total reactive power (kVAh)
• Hours Run
