Air-hydraulic jack for 50/25/10 tons

Air-Hydraulic Jack for 50/25/10 Tons

Country of origin: China, warranty period – 24 months

This is a professional air-hydraulic jack designed for lifting heavy-duty vehicles such as trucks or buses in service centers or workshops. Thanks to its three-stage construction, the device allows the user to choose the required lifting capacity and height, making it suitable for various situations. The unit is mobile, equipped with wheels for easy transportation, and operates using compressed air.

Features:

• Three-stage lifting mechanism – 50 t, 25 t, and 10 t
• Compact minimum height – only 152 mm
• Suitable for working with various heavy-duty vehicles
• Convenient mobility thanks to trolley design
• Durable and reliable body construction
• Operates with compressed air system (0.8–1.0 Mpa)

Technical specifications:

• Lifting capacity: 50 / 25 / 12.5 t
• Minimum height: 152 mm
• 1st stage lift height: 68 mm
• 2nd stage lift height: 73 mm
• 3rd stage lift height: 76 mm
• Maximum height: 369 mm
• Weight (net/gross): 63 / 65 kg
• Package size: 720 × 365 × 300 mm
• Working air pressure: 0.8–1.0 Mpa
