Air-hydraulic jack 50/25t

Air-Hydraulic Jack 50/25t

Country of origin: China, warranty period – 24 months

This is an exceptionally durable and professional air-hydraulic jack designed for heavy-duty vehicle maintenance – ideal for lifting trucks, buses, agricultural machinery, and fleet vehicles. The model features a piston head sealing technology commonly used in industrial equipment, ensuring excellent pressure retention and durability even under extreme loads. The three-stage lifting system allows for a maximum lifting height of 210 mm, while the extended 130 cm handle with three lockable positions enables easier access to hard-to-reach areas.

Features:

• SUPER HEAVY DUTY – robust construction for heavy lifting applications
• Solid one-piece base ensures greater stability and strength
• Industrial-grade piston seal design – better pressure retention
• Long 130 cm handle with 3 locking positions – improved handling
• Smooth and safe lowering – integrated flow control system
• Double-polished chrome-plated pistons – reduced oil bypass and wear
• Air-assisted lowering – faster piston retraction
• Built-in overload safety valve – protects the unit from excessive loads
• Mobile – equipped with wheels for easy transportation

Technical specifications:

• Lifting capacity: 50 t / 25 t / 10 t
• Minimum height: 210 mm
• 1st stage lift height: 102 mm (50 t)
• 2nd stage lift height: 25 mm (25 t)
• 3rd stage lift height: 94 mm (10 t)
• Maximum height: 431 mm
• Handle length: 1304 mm
• Body width: 165 mm
• Width at wheels: 289 mm
• Operating air pressure: 0.8–1.2 MPa
• Weight: 60 kg
