Ultrasonic tank 75 liters with lifting platform and filtration system AL-75 SONIXTEC

New

Ultrasonic tank 75 liters with lifting platform and filtration system AL-75 SONIXTEC

SKU: BD70896
SKU:: AL-75

11,999.00 €

SONIXTEC

Prices shown include tax

Add to Cart

Send Message

Description

Ultrasonic tank 75 liters with lifting platform and filtration system AL-75 SONIXTEC

Country of origin: Belgium, warranty period - 24 months

The industrial ultrasonic tank AL-75 from the SONIXTEC AL series is designed for intensive and precise cleaning in workshops and the manufacturing sector. This model features an automated pneumatic lifting platform that ensures easy loading and unloading of parts. The device is operated via a 7-inch touchscreen and controlled by a SIEMENS PLC controller. Built with a robust thick-walled stainless steel tank, this equipment offers advanced features such as Sweep, Degas, Pulse, and Dynamic modes, ensuring reliable cleaning even under the most demanding conditions.

Functions:

7-inch touchscreen
SIEMENS PLC control system
8 programmable automatic cleaning cycles
Thick-walled tank made of stainless steel 304
External panels made of stainless steel 304
Submersible transducer boxes made of stainless steel 316L
Reinforced pneumatic platform with agitation function up to 2000 kg
Laminar flow system and filtration system
Adjustable heating from 30 °C to 100 °C
Digital generator for more efficient cleaning
Sweep, Degas, Pulse, and Dynamic functions
Compressed air gun
Operating frequency 28 kHz or 40 kHz (other frequencies available)
Insulated lid with diamond-shaped drip collection system (optional automatic lid)
Sloped tank bottom for easy cleaning
Lockable castor wheels and vibration-dampening rubber feet
1" water inlet and 1" drain valve

Benefits:

Time-saving – ultrasonic tanks quickly and effectively remove contaminants
Wide range of contaminant removal – cleans various materials, surfaces, and parts
Deep cleaning – removes dirt even from microscopic crevices
Gentle on surfaces – cleans without friction or abrasion
Low energy consumption – efficient use of electricity and transducers
Eco-friendly – reduces the use of hazardous solvents and overall energy consumption
