Metal lathe Holzmann ED1000KDIG

Metal lathe Holzmann ED1000KDIG

Manufacturer: Holzmann (Austria)

Features:

State-of-the-art screw and feed metal lathes with exceptional long-term value

Ideal for use in sectors that require versatility, such as maintenance and production workshops, specialist workshops or for training purposes in schools

Extra wide shaft opening (Ø 52 mm) for machining large diameter metals

The electromagnetic foot brake ensures maximum work safety and significantly reduces non-productive time

Induction-hardened and precision-ground prismatic guides made of stabilized cast iron for maximum lifetime accuracy

The removable bridge allows you to process workpieces with a diameter of up to 550 mm

Precision-cut gears and anti-vibration cast iron lathe pad ensure high rotational accuracy

Gears and shafts are hardened, ground and run in an oil bath

Dynamically balanced main shaft, high rotational speed orientation (< 0.009 mm)

Variable speed setting with frequency converter, the speed can be set conveniently through the digital display

CAMLOCK D5 shaft holder

Standard two-stage engine

Digital 3-axis control unit

Adjustable (+/- 5mm) spike shank for taper rotation

All guides are conveniently adjustable through the V shape

Complete set: 3-piece chuck Ø 200 mm with exchangeable chucks, 4-piece chuck Ø 200 mm, front plate Ø 320 mm, 2x points MT4, morse taper sleeve MT6/4, feed cover, brake pedal, halogen work lamp, chip protection, cooling unit, stand with spindle brake, change gear, tools

Technical data:

Motor power s1: 2000 W

Power supply: 400V / 50Hz

Dimensions: 2070 x 780 x 1800 mm

Lathe width: 210 mm

Height of lathe: 270 mm

Longitudinal feed: 0.02-0.85 mm/U (64)

Cross feed: 0.005-0.22 mm/U (64)

Shaft bore: 56 mm

Shaft taper: MK6/MT6

Tailstock taper: MK4/MT4

Turning speed min-1: 45-2000 (12)

Max. tool holder cross-section: 30 x 20 mm

Metric thread range mm/r: 0.8-14 (36)

Inch Thread Range: 2-28 TPI (36)

Tailstock travel: 120 mm

Distance between centers: 1000 mm

Max. position above the lathe bed: 400 mm

Center height: 200 mm

Stroke: 730 mm

Cross slide stroke: 180 mm

Compound slide stroke: 115 mm

Noise level: 78 dB

Net weight: 800 kg

Gross weight: 900 kg
