Ultrasonic tank 600 liters with lifting platform and filtration system AL-600 SONIXTEC

Ultrasonic tank 600 liters with lifting platform and filtration system AL-600 SONIXTEC

Country of origin: Belgium, warranty period - 24 months

The industrial ultrasonic cleaning tank AL-600 from the SONIXTEC AL series is designed for demanding, professional, and intensive use. This unit features an automated pneumatic lifting system with an agitation function, which allows easy loading and unloading of cleaned objects. The device is operated via a 7-inch touchscreen and controlled by a Siemens PLC controller. AL series tanks stand out with their thick-walled AISI304 stainless steel construction, high-frequency ultrasonic cleaning, integrated filtration system with oil separation, and advanced cleaning functions. This equipment is widely used in the automotive, marine, engineering, defense, metal processing, aerospace parts production, weapons, and chemical industries.

Functions:

• 7-inch touchscreen
• SIEMENS PLC 8xI 6xO control system
• 8 programmable automatic cleaning cycles
• Thick-walled tank made of stainless steel 304
• Exterior panels made of stainless steel 304
• Submersible transducer boxes made of stainless steel 316L
• Reinforced pneumatic platform with agitation function up to 2000 kg
• Laminar flow system and filtration system with oil separation
• Adjustable heating from 30 °C to 100 °C
• Digital generator for more efficient cleaning
• Sweep, Degas, Pulse, and Dynamic functions
• Compressed air gun
• Insulated lid with diamond-shaped drip collection system (optional automatic lid)
• Sloped tank bottom for easy cleaning
• Lockable multifunctional castor wheels and vibration-dampening rubber feet
• 1" water inlet with ball valve and 1" drain connection
• Adjustable leveling feet
• Emergency stop switch and main power switch

Benefits:

• Time saving – ultrasonic tanks remove contaminants faster and more efficiently than traditional methods
• Wide contaminant removal range – effectively removes various types of contaminants from different surfaces
• Complex microscopic cleaning – high-frequency waves reach even the tiniest crevices
• Gentle on surfaces – cleaning occurs without friction or scrubbing
• Low power consumption – efficient use of electricity and transducers
• Environmentally friendly – reduces the use of hazardous solvents and overall energy consumption

Technical specifications:

• Model: AL-600
• Capacity: 600 liters
• Tank dimensions: 125 x 80 x 77 cm
• Useful tank dimensions: 116 x 71 x 45 cm
• External dimensions: 223 x 131 x 194.5 cm
• Maximum lifting capacity: 300 kg
• Power supply: 3-phase, 400V
• Heating power: 12000 W
• Ultrasonic power: 7200 W
• Operating frequency: 28 kHz or 40 kHz
• Number of ultrasonic transducers: 120
• Tank material: Stainless steel AISI304, 2.5 mm
• Weight: 700 kg

Applications:

• General workshops
• Diesel injection workshops
• Grinding workshops
• Turbocharger repair workshops
• Engine repair and rebuilding
• Gearbox repair workshops
• Marine industry
• Heavy machinery service
