Ultrasonic tank 400 liters with lifting platform and filtration system AL-400 SONIXTEC

Ultrasonic tank 400 liters with lifting platform and filtration system AL-400 SONIXTEC

Functions:

• 7-inch touchscreen
• SIEMENS PLC 8xI 6xO control system
• 8 programmable automatic cleaning cycles
• Thick-walled tank made of stainless steel 304
• External panels made of stainless steel 304
• Submersible transducer boxes made of stainless steel 316L
• Reinforced pneumatic platform with agitation function up to 2000 kg
• Laminar flow system and oil separation filtration system
• Adjustable heating from 30 °C to 100 °C
• Digital generator for more efficient cleaning
• Sweep, Degas, Pulse, and Dynamic functions
• Compressed air gun
• Insulated lid with diamond-shaped drip collection system (optional automatic lid)
• Sloped tank bottom for easy cleaning
• Lockable multifunctional castor wheels and vibration-dampening rubber feet
• 1" water inlet with ball valve and 1" drain connection
• Adjustable leveling feet
• Emergency stop switch and main power switch

Benefits:

• Time saving – ultrasonic cleaners can remove contaminants faster and more efficiently than traditional methods
• Contaminant removal – effectively eliminates a wide variety of contaminants from different materials and surfaces
• Complex microscopic cleaning – high-frequency waves reach even the smallest crevices, ensuring complete cleanliness
• Gentle cleaning – safe for delicate components, as cleaning is done without friction or abrasion
• Low power consumption – efficient use of electrical energy and transducers minimizes power usage
• Environmentally friendly – reduces or eliminates the use of hazardous solvents and lowers overall energy consumption

Technical specifications:

• Model: AL-400
• Capacity: 400 liters
• Tank dimensions: 110 x 61.5 x 69 cm
• Useful tank dimensions: 102 x 52 x 42 cm
• External dimensions: 172 x 100 x 190 cm
• Maximum lifting capacity: 200 kg
• Power supply: 3-phase, 240V / 400V
• Heating power: 9000 W
• Ultrasonic power: 5760 W
• Working frequency: 28 kHz or 40 kHz
• Number of ultrasonic transducers: 96
• Tank material: stainless steel AISI304, 2 mm
• Weight: 455 kg

Applications:

• General workshops
• Diesel injector workshops
• Grinding workshops
• Turbocharger repair workshops
• Engine repair and rebuilding
• Gearbox repair workshops
• Marine industry
• Heavy machinery service
