Ultrasonic tank 300 liters with lifting platform and filtration system AL-300 SONIXTEC

Ultrasonic tank 300 liters with lifting platform and filtration system AL-300 SONIXTEC

Country of origin: Belgium, warranty period - 24 months

The industrial ultrasonic cleaning tank AL-300 from the SONIXTEC AL series is designed for intensive and professional use where deep, effective, and gentle cleaning is required. The unit features an advanced pneumatic lifting platform with an agitation function that allows for easy loading and unloading of components. Operation is controlled via a 7-inch touchscreen and managed by a SIEMENS PLC controller. The robust construction made of thick-walled AISI304 stainless steel, integrated filtration system with oil separation, and high-frequency ultrasonic cleaning ensure reliable and long-term performance even in the most demanding industrial environments.

Functions:

• 7-inch touchscreen
• SIEMENS PLC 8xI 6xO control system
• 8 programmable automatic cleaning cycles
• Thick-walled tank made of stainless steel 304
• Exterior panels made of stainless steel 304
• Submersible transducer boxes made of stainless steel 316L
• Reinforced pneumatic platform with agitation function, up to 2000 kg
• Laminar flow and filtration system with oil separation
• Adjustable heating from 30 °C to 100 °C
• Digital generator for more efficient cleaning
• Sweep, Degas, Pulse, and Dynamic functions
• Compressed air gun
• Insulated lid with diamond-shaped drip collection system (optional automatic lid)
• Sloped tank bottom for easier cleaning
• Lockable multifunctional castor wheels and vibration-dampening rubber feet
• 1" water inlet with ball valve and 1" drain connection
• Adjustable leveling feet
• Emergency stop switch and main power switch

Benefits:

• Time saving – ultrasonic cleaners quickly and efficiently remove contaminants
• Wide range of contaminant removal – cleans various types of dirt from different surfaces
• Complex microscopic cleaning – high-frequency waves reach even the smallest crevices
• Gentle on surfaces – cleans without friction or abrasive action
• Low energy consumption – efficient use of electricity and transducers
• Eco-friendly – reduces the use of hazardous solvents and overall energy consumption

Technical specifications:

• Model: AL-300
• Capacity: 300 liters
• Tank dimensions: 90 x 61.5 x 64 cm
• Useful tank dimensions: 82 x 52 x 38 cm
• External dimensions: 155 x 100 x 180 cm
• Maximum lifting capacity: 200 kg
• Power supply: 3-phase, 240V / 400V
• Heating power: 9000 W
• Ultrasonic power: 3600 W
• Working frequency: 28 kHz or 40 kHz
• Number of ultrasonic transducers: 60
• Tank material: Stainless steel AISI304, 2 mm
• Weight: 399 kg

Applications:

• General workshops
• Diesel injector workshops
• Grinding workshops
• Turbocharger repair workshops
• Engine repair and rebuilding
• Gearbox repair workshops
• Marine industry
• Heavy machinery service
