Ultrasonic tank 150 liters with lifting platform and filtration system AL-150 SONIXTEC

Ultrasonic tank 150 liters with lifting platform and filtration system AL-150 SONIXTEC

Country of origin: Belgium, warranty period - 24 months

The industrial ultrasonic cleaner AL-150 from the SONIXTEC AL series is designed for demanding industrial and professional cleaning processes where powerful and deep cleaning is required. This device features an automated pneumatic lifting platform with an agitation function, allowing for easy loading and unloading of cleaned items, ensuring higher cleaning efficiency. The unit is operated via a 7-inch touchscreen and controlled by a SIEMENS PLC controller. The robust construction made of thick-walled stainless steel, integrated filtration system, and numerous advanced features ensure consistent and efficient performance across various industrial applications.

Functions:

• 7-inch touchscreen
• SIEMENS PLC 8xI 6xO control system
• 8 programmable automatic cleaning cycles
• Thick-walled tank made of stainless steel 304
• Exterior panels made of stainless steel 304
• Submersible transducer boxes made of stainless steel 316L
• Reinforced pneumatic lifting platform with agitation function up to 2000 kg
• Laminar flow and filtration system with oil separation
• Adjustable heating from 30 °C to 100 °C
• Digital generator for more efficient cleaning
• Sweep, Degas, Pulse, and Dynamic functions
• Compressed air gun
• Insulated lid with diamond-shaped drip collection system (automatic lid optional)
• Sloped tank bottom for easy cleaning
• Lockable multidirectional castor wheels and vibration-dampening rubber feet
• 1" water inlet with ball valve and 1" drain connection
• Adjustable leveling feet
• Emergency stop switch and main power switch

Benefits:

• Time saving – ultrasonic cleaners quickly and efficiently remove contaminants
• Wide range of contaminant removal – cleans various materials, surfaces, and components
• Deep cleaning – high-frequency waves remove dirt even from microscopic crevices
• Gentle on surfaces – cleans without friction or scrubbing
• Low energy consumption – efficient use of electricity and transducers
• Eco-friendly – reduces hazardous solvent usage and overall energy consumption

Technical specifications:

• Model: AL-150
• Capacity: 150 liters
• Tank dimensions: 70 x 51 x 53 cm
• Useful tank dimensions: 62 x 36 x 28 cm
• External dimensions: 129 x 93.5 x 161.8 cm
• Maximum lifting capacity: 125 kg
• Power supply: 3-phase, 240V / 400V
• Heating power: 5000 W
• Ultrasonic power: 2040 W
• Working frequency: 28 kHz or 40 kHz
• Number of ultrasonic transducers: 34
• Tank material: Stainless steel AISI304, 2 mm
• Weight: 325 kg

Applications:

• General workshops
• Diesel injector workshops
• Grinding workshops
• Turbocharger repair workshops
• Engine repair and rebuilding
• Gearbox repair workshops
• Marine industry
• Heavy machinery service
