Smoke generator Autool SDT203

Smoke generator Autool SDT203

Manufacturer: Autool

Autool SDT203 is a professional equipment that allows you to identify various car malfunctions and system leaks. The device will allow you to accurately and quickly determine the location of the problem in such systems as: intake, exhaust, fuel and vapor recirculation systems, cooling, tightness of turbine systems, etc.

Performing a leak test:

1. Add 20 ml of special liquid to the device.
2. Connect the device's smoke blowing nozzle to the system under test.
3. Connect the smoke generator to a 12 V power source, turn on the start button.
4. After about 30 seconds the system will be filled with smoke. At that time, try to look for leaky places through which smoke rushes.

Advantages of the smoke generator Autool SDT203:

• A very wide range of applications. You will be able to test not only various car systems, but also motorcycle, ATV, and boat systems
• A powerful and easy-to-use device. It has a built-in small compressor, so all you have to do is connect the power supply wires to a 12V DC source and it will charge in 30 seconds. is ready to fulfill its purpose
• Advanced technology to work with the EVAP system. The device has two flow meters that allow accurate monitoring of parameter data. You also have the option to adjust the air and smoke flow separately
• Protection against overheating and freezing. The generator has an intelligent protection that allows the device to work even up to a temperature of 75 °C. If the safe temperature limits are exceeded, the device is forced to shut down
• 3 year warranty
• Light weight of the device

Components that make up the device:

• Pressure gauge
• Plug for adding test oil
• Flow Meter
• Oil gauge
• Power outlet
• Smoke outlet connection
• Smoke flow control valve
• Warning signals

Technical parameters:

• Output flow: 6 L/min
• Air outlet: built-in small compressor
• Power supply: 12 V / DC
• Device dimensions: 190 x 130 x 85 mm
• Device weight: 2.5 kg
• Package dimensions: 227 x 160 x 242 mm

The set includes:

• 1 x Autool SDT2003 smoke generator
• 1 x power cords
• 1 x smoke Hose
• 1 x standard taper adapter
• 1 x universal Inflatable Seal Pump
• 1 x hard rubber plug
• 1 x hook
• 1 x funnel
• 1 x user manual
