MaxiEV BCE100 cell balancing device for electric car batteries

MaxiEV BCE100 cell balancing device for electric car batteries

Autel MaxiEV BCE100 is an innovative and advanced battery balancing device for accurate balancing and calibration of batteries. This advanced device is essential to avoid overcharging and over-discharging, ensuring an even distribution of charge between all cells of the module. Such functionality is critical to optimizing the overall performance and longevity of battery packs, especially in high-demand applications such as electric vehicles and renewable energy storage. The BCE100 excels by accurately detecting and correcting voltage and current mismatches between cells, which is essential to maintain consistent and reliable charging cycles. Its advanced algorithms and high-precision sensors allow the device to precisely adjust the voltage and current, ensuring that each battery cell is charged to the maximum without suffering any damage.

Features:

• Battery cell cells are detected and charged evenly and consistently to prevent cell overload
• Ensures accurate measurement results by detecting and correcting voltage and current values
• Over voltage protection to keep the cell voltage close to the target limit during the test
• Additional protection against voltage, overcurrent, short circuit or improper pole connection

Technical data:

• Charge and discharge voltage range: 1.8 - 5V
• Charge and discharge current range: 0.1 - 5 A
• Voltage detection accuracy: ± 0.1% FS ±2 mV (maximum range: 5 V)
• Current measurement accuracy: + 1% FS ±0.05 A (maximum range 5 A)
• Charging and discharging power: max. 600 W
• Cell quality test: max. 2 packs of 12 cells, one pack supports 2 x 12 / 1 x 24)
• Power supply: 230 V / AC
• Charge management: DC and voltage charging
• Discharge working mode: direct current
• Protective functions: Protection against excessive voltage, current and temperature
• Dimensions: 496 x 246 x 262 mm
• Weight: 14 kg
