MaxiEV CDT100 charging / discharging device for electric car batteries

MaxiEV CDT100 charging / discharging device for electric car batteries

Autel MaxiEV CDT100 is an advanced high-voltage battery charger and discharger designed to improve the performance and capacity of battery batteries through precise and efficient charge and discharge cycles. This state-of-the-art device is essential for maintaining and optimizing the health and longevity of high-voltage storage batteries, making it an invaluable tool in a variety of industries. The CDT100 is an essential tool for anyone involved in the maintenance, repair and management of high voltage storage batteries. Its advanced features and reliability make it an exceptional choice for professionals seeking the highest quality standards. Whether you manage a fleet of electric vehicles or maintain individual battery banks, the MaxiEV CDT100 will provide the reliability and functionality you need.

Features:

• Wide voltage range, suitable for discharging, charging or exciting batteries of various voltages
• Determine DC current and voltage, charge or discharge different types of battery cells
• The maximum and minimum voltage of one cell is displayed, as well as other parameters: graphs, columns and report forms. The ability to zoom in without zooming out the displayed results
• Optimize the battery capacity of batteries with constant current discharge or charge modes
• Improper polarity connection warning, over temperature, over current, cooling fan or overload warnings and protections
• Improves charging efficiency and ensures full charging

Application:

• Accumulator batteries / for vehicle transport:

Safely discharge battery packs per DOT vehicle requirements (Air: 20%; Land/Sea: 40%)

For car dealers who transport EVs and hybrids from one location to another

• Repair of passenger cars and commercial vehicles:

In order to ensure safety, direct charging and discharging of the car is carried out before, after or during the repair of the car

Be sure to discharge the car's battery before parking it in the paint booth

Restore the performance and range of your batteries by properly balancing them

• In car warehouses and dismantling workshops:

Prevent the risk of fire when discharging batteries

Technical parameters:

• Charge - discharge voltage range: 2 - 285 V / DC
• Accuracy: ± 0.5 FS
• Cell voltage range: 0-5V
• Cell voltage accuracy: 0.001V
• Discharge current range: 150 A / 7.2 kW max.
• Discharge current accuracy: ± 1 FS
• Charging current range: 100 A / 4.4 kW max.
• Charging current accuracy: ± 1 FS
• Power supply: 230 V / AC
• Operating modes: discharge, charge and excitation
• Device safety: Multiple DC protection against over-voltage, mixed pole connection, over-current discharge and over-temperature of the system
• Dimensions: 530 x 300 x 350 mm
• Weight: 23.4 kg
