Innovare BodyGuard car body defect inspection system

Innovare BodyGuard car body defect inspection system

BL Innovare BodyGuard production is a revolutionary equipment that changes the usual, established car inspection work. This change is possible thanks to the use of non-contact posts that perform car inspections even while they are moving. Equipment manufacturers have set a goal to ensure that the inspections performed are fast, accurate and economical. They are also committed to innovations that encourage regular equipment updates so that it always meets world-class needs. We can say that this is a modern and effective security system designed to meet the highest needs. This device ensures security and a guarantee of safety that protects companies from unfounded and inappropriate complaints about damaged cars.

How the equipment works:

• Integrated Smart lights (for body lighting) are activated by an approaching vehicle
• Strategically installed video cameras start recording the approaching vehicle
• The recorded vehicle data is identified by the license plate number of the vehicle that passed by. Also, this data is uploaded to the web server
• The sent recorded data can be viewed on the web server. (Upload speed depends on the traffic of vehicles and internet speed)
• You can find a specific car by the license plate of this car
• You can select a specific video camera that has recorded cars from various sides and view all the recorded video material

Features:

• The system has the ability to record various defects that are not visible under normal conditions
• The ability to record various rim damage, scratches even when the car is moving at a speed of 5 - 8 km/h
• Various car dents are recorded, even when the cars are wet and moving
• Comprehensive, easy-to-understand software is used, which allows you to view all the cars recorded by the system and find out their condition.
• Possibility of using the equipment indoors or outdoors
• The equipment can work with car flows in two directions

Capture existing car damage

• 360 ° vehicle coverage, thanks to the installed 6 or 10 video cameras from different angles
• Integrated lighting ensures high-resolution photo capture
• The ability to work with dirty, wet or other condition cars

Very simple integration of the system into your workshop

• Fully automatic system that does not require interrupting any of your work in the workshop
• The system scans all cars that pass the installed scanning posts
• The BodyGuard API system is easy to integrate into any of your premises or areas

Easy to use, high-quality photos

• User-friendly and simple control menu
• Automatic scanning and assignment of vehicle numbers, much easier data management
• Designed to capture various defects on a moving vehicle

Allows you to abandon the usual, long specialists checks

• Continuous data processing and storage
• Improved work efficiency thanks to automated technology
• The ability to free your employees from additional work with customers

The equipment is most widely used in the following areas:

• Car dealerships
• Car washes
• Car parking lots
• Tire repair shops
• Car rental points
• Car factories
• Companies with a large car fleet
• Car auctions

Technical parameters:

• Distance between columns: 3000 – 5000 mm
• Operating temperature: from -30 °C to + 50 °C
• Power supply: 240 V / 50 Hz
• Power consumption: 300 W
• Internet connection requirements: 15 MBps (wired connection)
• Internet cable requirements (inside): 16 AWG 2 – copper, 1 – Cat6 server box columns
• Internet cable requirements (outdoor): 16 AWG 2 – copper, 4 – Cat6 server box columns
• Maximum cable length from column to posts: 25 m
• Dimensions with video cameras (BodyGuard 1.2), (L x W x H): 314 x 222 x 2127 mm
• Dimensions with video cameras (BodyGuard 1.2 tall), (L x W x H): 314 x 222 x 2802 mm
• Base dimensions: 237 x 179 mm
• Server box dimensions (switch), (L x W x D): 413 x 504 x 128 mm

Available device models:

• BodyGuard 1.2
• BodyGuard 1.2 tall
• BodyGuard 1.2 (adapted for outdoor conditions)
• BodyGuard 1.2 tall (adapted for outdoor conditions)
• License package BodyGuard 1.2 (<100 cars per day)
• License package BodyGuard 1.2 (additional 100 cars)
• License package BodyGuard 1.2 tall (<100 cars per day)
• License package BodyGuard 1.2 tall (additional 100 cars)

Additionally ordered components:

• Additional lighting stands (60000 lm)
• Additional car roof damage detection system with two video cameras
