Four column lift with axle lift, 8000 kg, BD-8000

Four column lift with axle lift, 8000 kg, BD-8000

The four-column lift BD-8000 with integrated axle lift is a reliable and robust solution for professional use in automotive workshops. This lift is capable of lifting vehicles up to 8000 kg, so it is perfect for working with trucks, vans or industrial vehicles. The high-quality construction ensures stability and durability, and four strong columns provide maximum safety during work. The integrated axle lifter allows you to comfortably lift and adjust vehicle axles, which is especially useful for wheel alignment, maintenance and repairs. This lift ensures maximum efficiency and safety, making it an excellent choice for both service and industrial workshops.

Features:

• Pneumatic unlocking mechanism
• Complete with 2.5 ton electro-hydraulic axle lift
• The solid steel structure ensures the stability of the lift
• Integrated rear sliding plates
• The crossbars are made with easy access and removal, thus facilitating the maintenance process
• Ropes with emergency locking in case of breakage
• Aluminum motor construction ensures good heat dissipation and long service life

Technical parameters:

• Load capacity: 8000 kg
• Platform length: 5500 or 6000 mm
• Total height: 2480 mm
• Minimum height: 240 mm
• Platform width: 650 mm
• Distance between platforms: 1100 mm
• Motor power: 3.0 kW
• Power supply: 230 - 400 V / 50 Hz
• Lifting time: 110 sec
• Maximum lifting height: 1500 - 1700 mm
• Weight: 2600 kg
