Automatic parts washer Marwis 2 in 1 hydro wash 1200

Automatic parts washer Marwis 2 in 1 hydro wash 1200

Manufacturer: Marwis. Country: Poland.

HYDRO WASH is a combination of modern technology and diligence. MARWIS uses proven solutions based on many years of experience at every stage of the washing machine development, from design to assembly, but is also not afraid to use innovative ideas to provide the customer with highly efficient and reliable equipment. The Hydro-Wash is a multifunctional device that allows you to wash parts fully automatically with a motorized rotating basket or more complex shaped parts - 140 bar wash. Due to the combination of these processes, it is safe to say that the device will be used in all workshops. This will successfully improve the performance of a company that regenerates turbochargers, steering gears and gearboxes. To ensure the safety of the user and the stability of the washing parameter, an electronic control panel and a number of sensors cooperating with it were used.

Standard washing equipment:

Closing lid release sensor when opened during washing

Liquid level sensor in the tank to prevent dry running,

Liquid temperature sensor,

Adjustable spray arms with stainless steel nozzles from a famous spray system company

Mechanically rotating basket,

High pressure pump 140 bar

Compressed air gun

Pressure reducer with dirt collector

Coarse insoluble impurity filter (mesh filter, mesh size 0,8 mm)

Fine dirt filter

Adjustable feet

Drain valve

pneumatic drives

Technical data:

Basket diameter: 1200 mm

Working height: 500 mm

Carrying capacity of the bag: 300 kg

Working time programming: 0-99 min

Washing temperature: 60 ° C

Heater power: 12kW

Bako capacity: 400l

Spraying capacity: 200 l / min

Spraying working pressure: 4.5-6 bar

Manual washing pressure: 140 bar

Overall width: 1750 mm

Overall depth: 1750 mm

Total height: 1700 (2650 mm open) mm

Power: 3 ~ 400V
