Electronic headlamp tester equipped with a camera for complete analysis and verification of any type of headlamp.
- The aluminum stand is equipped with a counterweight balancing system that allows the optical box to be moved with light touch on both sides.
- The cast optical box is equipped with a 230mm diameter pure glass lens. The structural specifications allow the verification of deviations of the mechanical position of the light from 1 cm to 10 meters.
- The optical box has both RS232 and USB connection.
- Steel and aluminum base with three height-adjustable castors.
Scanning options:
- Halogen, xenon, led, low beam, high beam, fog light, light pattern, European left / right hand drive, England, USA, Japan.
Available configurations:
- Tecnolux Moon L1 12799: complete with mirror panel and laser application system
- Tecnolux Moon L2 12799: complete with laser panel and laser application system
- Tecnloux Moon L1 LAN 12799: complete with mirror panel, laser application system, inclinometer and protocol converter
- Tecnolux Moon L2 LAN 12799: complete with laser panel, laser application system, inclinometer and protocol converter
