DPF / CAT / FAP Filter Cleaning Equipment DPF4001+ for All Types of Filters

DPF / CAT / FAP Filter Cleaning Equipment DPF4001+ for All Types of Filters

Country of origin: Turkey, warranty period - 24 months

DPF4001+ is an advanced filter cleaning device designed for all types of filters, including those used in passenger cars, vans, trucks, Euro 4 / 5 / 6 vehicles, and agricultural machinery. Cleaning is performed using a high-pressure water jet combined with a special detergent. The equipment allows for checking the condition of filters both before and after cleaning, ensuring high cleaning efficiency. After cleaning, the filters are quickly dried using a hot air drying system.

Cleaning Process:

The average cleaning time for a single filter is 20–30 minutes, depending on the level of contamination. Without changing the water, 5–10 cleanings can be performed, depending on filter contamination. One kilogram of detergent is sufficient to clean approximately five filters. The equipment comes with 10 kg of detergent.

Features:

• Made of stainless steel
• Manual and automatic cleaning programs
• Water temperature control
• Water level sensor
• Cleaning time adjustment
• Touchscreen control panel with Android operating system
• Drying system
• Hydraulic connection
• Pneumatic platform
• Cartridge filters
• Mechanical and pneumatic protective doors
• Electrical components meet EU safety standards
• All standard adapters included
• Serviced Filters:
• All types, including those for passenger cars, vans, trucks, Euro 4 / 5 / 6 vehicles, and agricultural machinery

Technical Specifications:

• Working dimensions: 1800 x 600 x 1000 mm
• Operating weight: 800 kg
• Tank capacity: 250 l
• Cleaning pump power: 3 kW
• Maximum water temperature: 80°C
• Water heater power: 2 x 7.5 kW
• Drying temperature: 200°C
• Drying system power: 3 kW
• Electronic components: Schneider / ABB Electric
• Compliance: CE
• Exhaust fan power: 0.75 kW
• Doors: pneumatic
• Water filters: tank filter, cartridge, and bag filters made of stainless steel
• Inspection: before and after cleaning
• Software: Android
• Control system: PLC system (touchscreen)
• Required compressed air connection: 10 bar
• Cleaning programs: automatic or manual
• Hydraulic connections: secure mounting for passenger car filters
• Pneumatic platform: FAP / DPF filter fixation
• Additional accessories: water level sensor, tank insulation, all standard connections, manual cleaning gun
• Wi-Fi Industry 4.0 technology: optional
• Material: stainless steel
• Power supply: 400 V / 3-phase / 50 Hz or 230 V / 1-phase / 50 Hz
• Dimensions: 2400 x 1050 x 2000 mm
