Battery tester GYS PBT 600
Battery tester GYS PBT 600

Battery tester GYS PBT 600

  • SKU: BD34420
242.00 €

Prices shown include tax

Send Message

Description

Battery tester GYS PBT 600



GYS, France; Warranty: 24 months



Description:



A professional battery tester with ultra-accurate results and an integrated printer.

Suitable for working with cars and vans.

- 12V batteries: voltage and charge status check

- 12V and 24V starters: starting voltage check

- 12V and 24V generators: No-load voltage check and charging voltage, and current insulation during charging.

- Special function for internal battery resistance testing

Instantaneous experience: battery voltage (from 6V to 30V); possible starting powers; charge status and battery status.

Supported batteries: Several types of lead acid batteries with a capacity of 30 to 200 Ah are supported, including sealed batteries VRLA / GEL / AGM FLAT / AGM Spiral, standard liquid batteries and START / STOP batteries (EFB / AGM).

Operating limits:

- EN: 100> 2000 CCA

- DIN: 100> 1400 CCA

- SAE: 100> 2000 CCA

- IEC: 100> 1400 CCA (international standard)

- CA / MCA: 100> 2000 CCA (for water transport batteries)

Automatic outdoor temperature compensation. Advanced dynamic resistance measurement technology minimizes battery discharge and displays accurate results without being affected by: surface charging; parasitic load consumers (lamps and other indicators); contact inaccuracies (worn connections, loose connections, etc.).

Adjustable screen brightness, full inspection report showing date and time, and the ability to change the name; on standby; multi-language interface; replaceable terminals; pole reversal protection; ABS housing (acid resistant) and anti-electrification protection. Power supply 1x 9V battery (included).



Technical parameters:



- Supported batteries: 12V

- Capacity of supported batteries: 30 - 200 Ah

- Battery current indication: yes

- Battery voltage indication: yes, min. 6V

- Start-up and charging system check: 12V / 24V

- Display of results: within 1 s

- Cord length: 120 cm

- Weight: 1.1 kg

- Code: 024205
