Weber C - 1.25 single - column screw lift

Weber C - 1.25 single - column screw lift

Description:

- Electromechanical single-column car and minibus lift

- The 45 mm threads and bearings with nuts used in these lifts are among the largest on the market. Their size alone reduces friction and at the same time wear.

- The steel column profiles are hot rolled, so they have a light but strong construction

- One of the most stable single-column lifts in its category

- The lifting operation is performed fully with the button, so the height can be precisely adjusted

- The height of the column is made as low as possible so that the lift can be used in rooms with low ceilings

- The raised vehicle is easily accessible from three sides

- Unobstructed access to the car door on the other side of the column

- The side paws of the column are equipped with large tool trays

- The support is moved by long-term castors mounted on solid bearings

- Automatic ground brake: the lift will stop in the event of an obstacle or reach the floor

- The lift must be attached to the floor

Technical specifications:

- Lifting capacity: 2500 kg

- Max. lifting height: 1970 mm

- Min. lifting height: 110 mm

- Height of the ramp: 100 mm

- Column height: 2640 mm

- Base width: 1600 mm

- Minimum ceiling height required: 2805 mm

- Weight: 630 kg

- Engine power: 3.6 kW

- Length of short paws (rear): 582 - 785 mm

- Length of long paws (front): 700 - 980 mm

- Lifting time: 45 s

- Power supply: 400V / 3 phases / 50 Hz

- Column color: gray - RAL 9006

- Paw color: blue - RAL 5002
