Spot welding machine GYS GYSPOT COMBI 230 E PRO

Spot Welding Machine GYS GYSPOT COMBI 230 E PRO

Features:

• Suitable for working with both steel and aluminum in one device
• For steel: manual torch with automatic trigger function
• Adjustable output power and tool selection
• For aluminum: microprocessor control with digital display
• Adjustable voltage (50–200 V) and power levels (0–10)
• Automatic stud welding with magnetic torch attachment
• Compatible with AlSi and AlMg alloys
• Welding process does not require welding time setting
• Supplied with all necessary cables, torches, and consumables

Technical specifications:

• Power supply: 230 V, 50/60 Hz
• Output current (Imax): 3,800 A (steel), 13,000 A (aluminum)
• Welding current adjustment (U2): 50–200 A (steel)
• Control: manual (steel), automatic (aluminum)
• Aluminum torch cable: 3 m (Ø 25 mm²)
• Steel torch cable: 2 m (Ø 70 mm²)
• Dimensions: 45 x 43 x 29 cm
• Weight: 49.7 kg

Scope of delivery:

• For steel: grounding cable, multifunction torch, studs, washers, contact welding and electrode kit, consumables box, 8 m power cable
• For aluminum: M4 stud torch, aluminum studs, aluminum rods, contact connectors, magnetic mounting system, consumables box
