Battery charger - starter 12/24V GYS Neostart 620

Battery Charger - Starter 12/24V GYS Neostart 620

Functions:

• Charging 12V and 24V batteries
• Vehicle starting in case of a discharged battery
• High-power standard starting and charging cables
• Protection against short circuits, polarity reversal, and overloads
• Storage compartment for cables and clamps
• Integrated wheels for easier transportation
• Large ammeter for voltage monitoring

Technical Specifications:

• Power supply: 230V / 1 phase / 50-60Hz
• Current: 16A
• Power: 3100 W
• Supported batteries: 12 – 24V
• Battery capacity: 20 – 1350 Ah
• Effective current (RMS): 90A
• Average charging current: 60A
• Starting current for partially charged batteries: 360A
• Starting current for fully discharged batteries: 620A
• Maximum charging power: 1600 W
• Maximum starting power: 10 kW
• Cables: 16 mm², length – 2 m (red), 1.8 m (black)
• Brass clamps
• Fuse: 200 A
• Protection rating: IP21
• Dimensions: 470 x 320 x 270 mm
• Weight: 24.0 kg
