Oil collection tank with suction and drain function 90 l (with plastic container)

Oil Collection Tank with Suction and Drain Function 90 l (with Plastic Container)

Functions:

• Suitable for oil collection, suction, and draining
• Height-adjustable construction (from 1100 mm to 1680 mm)
• Transparent plastic container for monitoring oil volume
• Includes 5 probes of different diameters for various applications
• Suitable for working with oil at temperatures between 40–60 °C

Technical specifications:

• Total capacity: 90 l
• Plastic container capacity: 9 l
• Air inlet pressure: 6–8 bar
• Suction pressure: 0.6–0.8 bar
• Air consumption: 150 l/min
• Suction hose length: 1.5 m
• Recommended oil temperature: 40–60 °C
• Height adjustment: 1100–1680 mm
• Weight: 21.3 kg
• Package dimensions: 470 x 440 x 940 mm and 270 x 270 x 575 mm

Suction probes:

• 1 pc. PVC Ø 5 mm, length 700 mm (flow rate 1.4 l/min)
• 1 pc. PVC Ø 6 mm, length 700 mm (flow rate 2.8 l/min)
• 2 pcs. PVC Ø 7 mm, length 1000 mm (flow rate 3.2 l/min)
• 1 pc. PVC Ø 8 mm, length 700 mm (flow rate 5.0 l/min)
