Hand hydraulic axle jack AC Hydraulic SD26L
Hand hydraulic axle jack AC Hydraulic SD26L
Hand hydraulic axle jack AC Hydraulic SD26L
Hand hydraulic axle jack AC Hydraulic SD26L
Hand hydraulic axle jack AC Hydraulic SD26L

Hand hydraulic axle jack AC Hydraulic SD26L

  • SKU: BD13280
1,802.90 €

Prices shown include tax

Send Message

Description

Hand hydraulic axle jack AC Hydraulic SD26L


AC-Hydraulic, Denmark; Warranty: 3 years for hydraulics and 10 years for body parts

Manual hydraulic axle lift for cars and vans

Description:

- Quick and efficient lifting thanks to a manual double action pump
- The low lift height of 180 mm makes this device easy to use with low-floor cars
- Flexible support beam can be extended up to 1610 mm
- Unique height adjustable armrest system - Designed to fit all modern lifts and pits
- Two-hand lowering operation with emergency release, automatic safety locking device and overload valve for optimum safety
- Supplied with 3 extension kits (10/40/85 mm) and rubber cushion for body protection
- Manufacturer: Denmark
- Warranty: 3 years

Specification:

- Lifting capacity: 2.6 tonnes
- Lifting stroke: 250 mm
- Minimum height: 180 mm
- Length of supports: 780 - 1610 mm
- Lift width: 780 - 1180 mm
- Construction height: 120 mm
- Construction depth: 250 mm
- Weight: 105 kg

Additional equipment:

- HSD: Pneumatic connection kit
- FSD1: 130 mm height extensions (Requires 2 pcs)
- FSD2: Rubber support 40 mm (Requires 2 pcs.)
- FSD3: Rubber support 80 mm (Requires 2 pcs.)
- FSD5: Saddle with thread (106 - 240 mm) (Requires 2 pcs)
- FSD6: Height adjustable saddle (32 - 92 mm) (Requires 2 pcs)
- FSD7: Height extension 60 mm (Requires 2 pcs.)
- GS1: Rubber Pad for FSD6 (Requires 2 pcs)
- GS2: 10mm Rubber Pad (Requires 2pcs)
