Pneumo-hydraulic axle lifter AC Hydraulic SD20PHL-W 2.0t

Pneumo-hydraulic axle lifter AC Hydraulic SD20PHL-W 2.0t

AC-Hydraulic, Denmark; Warranty: 3 years for hydraulics and 10 years for body parts

Features:

The support beam can be extended up to 1865 mm

Only 190 mm minimum height, optimal for vehicles with low ground clearance

Fast and reliable lifting thanks to a faster and more efficient pump

Unique adjustable height mounting bracket system to fit any lift

Two-handed lowering operation with quick release

Complete with 3 extension kits (10/40/85mm) and a rubber pad to protect the car body

New Pump - The new axle lifter has an improved pump that provides even greater reliability as well as over 50% faster lifting and lowering.

A unique height-adjustable mounting bracket system that ensures a perfect connection to any lift - regardless of manufacturer

Ensures that electric vehicles can be lifted without damaging the battery

Technical data:

Lifting capacity: 2.0 t

Lifting stroke: 250 mm

Minimum height: 190 mm

Length of supports: 780 - 1865 mm

Lift width: 780 - 1180 mm

Construction height: 120 mm

Construction depth: 250 mm

Required compressed air pressure: 8-10 bar

Required compressed air flow: 400 - 700 l/min

Weight: 120 kg
