Pneumatic hoist with two-stage drive T22050

Pneumatic hoist with two-stage drive T22050

Product description

Manufacturer: Castex, Poland;

• Pneumatic lifter with two-stage actuator.
• The presented lift is equipped with a two-stage cylinder:
• I lifting capacity 25T
• II 50T
• Cooperation with air compressors and the use of pneumatic drive enables quick lifting without the need for large amounts of force.
• Lifting and lowering is carried out by means of a valve located on the adjustable handle of the hoist, which can be set in several positions at the preferred angles.
• The large hydraulic wheels ensure easy movement of the hydraulic-pneumatic lift.
• Strengthened, resistant to mechanical damage structure and components of the highest quality guarantee trouble-free, optimal operation of the lift.
• Technical data
• Height min. 210 mm
• Height max. 406 mm
• Piston stroke 106 mm
• Extension of the second piston 94 mm
• Net weight 73 kg
• The packaging dimension is 1410x300x290 mm
