Mobile gantry crane Delta 100

Mobile gantry crane Delta 100

Manufacturer: Mipromet, Poland

Mobile, selectable gantry crane Delta 100 - designed for moving, lifting, and lowering objects in various workplaces. The lifting capacity of the crane is determined in general, it covers the entire length of the beam and does not depend on the position of the lifting winch on it.

Advantages:

• Two height-adjustable side stands, foldable
• Adjustable horizontal length of gantry crane
• Crank for height adjustment (to use only without load)
• Chassis with brake and polyurethane tires
• Upper drive beam
• Trolley: manual
• Chain hoist: manual

Electric hoist gantry cranes are equipped with:

• An electric box with a receiving socket
• Spiral-twisted, flexible power cable
• An additional possibility to install an electrical socket on the lifting winch, which would allow the use of, for example: vacuum grippers, with an electric pumps
• Chassis - four swivel castors with brakes

Mobile gantry crane Delta 100 allows for adjustment:

• The height of the support beam
• The height of the driving supports
• The length of the working part of the support beam
• The crane can be folded or disassembled into simple components, making it easier to service, transport or store.

Wheelsets can be optionally equipped with:

• Direct lock, every 90°
• Wheel protection

Height adjustment mechanism:

• Lifting and lowering using a crank, and a screw is used to lock the height.

Technical parameters:

• Lifting capacity of the gantry crane: 1500 kg
• Crane height from the ground to the beam, "H": 1702 - 3002 mm
• Working width of the crane, "L": 1600 - 3850 mm
• Distance between crane support wheels, "D": 1488 mm
• Adjustable undercarriage height at a distance of 100 mm "dH".
• Adjustable working width of the crane, in "dL" steps: 250 mm
• Weight: 350 kg
