Marine outboard engine diagnostic tool JalTest PC Link
- SKU: BD25100-3
2,499.00 €
Send Message
Description
Marine Outboard Engine Diagnostic Tool JalTest PC Link
Professional equipment for the maintenance of outboard engines, boats, and vessels.
JalTest PC Link is a professional, universal diagnostic device designed to carry out precise analysis of electrical and electronic systems in boats, vessels, and other watercraft with outboard engines.
JalTest PC Link is built for specialists seeking a reliable and comprehensive diagnostic solution when working with outboard engine systems. The tool ensures fast, accurate, and universal access to various watercraft manufacturers’ systems, enabling complete ECU diagnostics, fault code reading, and operation via both USB and Bluetooth connections. It’s a solution for those aiming to optimize service workflows and expand their workshop’s capabilities.
Why Choose JalTest PC Link?
- Extensive market coverage
- Supports over 99.5% of current boats and vessels — no diagnostic limitations.
- One tool – many possibilities
- Usable not only for marine vehicles — also suitable for trucks, buses, trailers, agricultural and construction machinery.
- Regular updates and database expansion
- Software updated three times per year — always compatible with the latest systems and models.
- Flexible use in all conditions
- Connect via USB or Bluetooth (up to 50 m) — convenient for both shop and mobile diagnostics.
- Universal cables and adapters
- Easily connect to any diagnostic port — fewer tools, more efficiency.
- Durable and weather-resistant
- Shockproof and rugged housing — built for demanding outdoor environments.
Jaltest Marine Diagnostic Coverage:
- Watercraft brands supported: 84 and growing
- Watercraft models supported: 1499 and growing
- Technical database entries: 2861 and growing
- Electronic diagram entries: 2137 and growing
Standard Package:
- Jaltest Marine Outboard software 74502004
- Jaltest Marine Outboard license 74602004
Technical Specifications:
- Connects to desktop or laptop via Bluetooth or USB cable
- Bluetooth range: 20–50 m
- Minimum PC requirements: DVD drive, Windows XP, 7, 8, 10 64-bit OS, 2 GB RAM, 10 GB free hard disk space, USB port
- Power supply via OBD connector or 12/24 V DC power adapter
- Power consumption: 7W
- Shock-resistant housing
- Weight: 1.2 kg
- Dimensions: 183 x 131 x 56 mm
- Operating temperature: 0°C to +45°C
- Multilingual interface
- Certifications: CE, FCC, RoHS
Tester Features and Capabilities:
- ECU diagnostics via OBD interface or specific adapter
- Ability to connect to any diagnostic port using a universal diagnostic cable with specialized terminals
- Integrated automatic multiplexer — automatic switching of K and L, CAN, SAE lines to any OBD connector pin
- Supported diagnostic protocols:
- ISO 9141-2, K/L lines;
- ISO 14230 (KWP2000), K/L lines;
- SAE-J1850 VPW and PWM;
- ISO 11519-2;
- SAE J1708;
- ISO 15765-4 (OBD);
- CAN ISO 11898;
- CAN (High Speed, Middle Speed, Low Speed, single-wire CAN systems);
- SCI Haldex;
- RP 1210;
- SAE J2534 (PASS-THRU)
Who Is This Device For?
- JalTest PC Link is the ideal choice for workshops, independent technicians, and service professionals working with boats, outboard engines, vessels, jet skis, and stationary marine engines. It’s a solution for those looking to expand their services and reliably diagnose marine equipment.
