Manual pallet stacker 1000 kg GM10-16 FORK

Manual Pallet Stacker 1000 kg GM10-16 FORK

Country of origin: Latvia, warranty period - 24 months

Higher lifting versions of this stacker are available!

The FORK GM10-16 is a manual pallet stacker designed for lifting loads of up to 1000 kg to a height of 1600 mm. Its reliable construction, ergonomic operation, and compact dimensions make it suitable for use in smaller warehouses, workshops, or retail spaces. It is an economical and functional solution for small businesses or individual users looking to efficiently organize pallet storage and transport.

Functions:

• Ergonomic handle – for comfortable and safe operation
• Easy maneuverability – thanks to high-quality wheels and optimal turning radius
• Steel construction – durable and resistant to loads
• Economical solution – ideal for small warehouses
• Easy maintenance – no complex servicing required

Technical specifications:

• Load capacity: 1000 kg
• Fork length: 1070 mm
• Lifting height: 1600 mm
• Lowered fork height: 75 mm
• Overall length: 1480 mm
• Overall width: 1360 mm
• Load wheel size (single): 80 x 50 mm
• Steering wheel diameter: 150 x 50 mm
• Turning radius: 1650 mm
• Wheel material: polyurethane / nylon
